Houston’s location in a hurricane-prone region, combined with its rigorous permitting environment, demands careful attention to wind-borne debris protection on residential permit drawings. All aspects of fenestration-openings, protection, anchorage, schedules, shutter deployment, and plan review resubmissions-must be meticulously documented on the construction sheets, coordinated with local amendments to the 2018/2021 IRC and IBC, and supported by explicit manufacturer and code references.

Translating Houston's Wind-Borne Debris Code Requirements onto Residential Plans

Every residential permit plan in Houston must trace wind-borne debris requirements directly from code to construction sheet, beginning with region delineation and culminating in detailed protection notes. Per Section R301.2.1.2 of the 2018 IRC, as amended by Houston (Houston Residential Code Amendments), “exterior glazing in wind-borne debris regions shall be protected from windborne debris.”

Identifying Wind-Borne Debris Regions on Plan Sets

Houston is designated a hurricane-prone zone under ASCE 7-16, affecting all residential Risk Category II construction. The critical threshold is the 140 mph ultimate design wind speed (ASCE 7-16 Figure 26.5-1B). By code, wind-borne debris regions “are areas within hurricane-prone regions located: (1) within 1 mile of the coastal mean high water line where the ultimate design wind speed is 130 mph or greater; or (2) in areas where the ultimate design wind speed is 140 mph or greater.”

Houston drawings must include explicit documentation of the site’s wind speed per the ASCE 7 Hazard Tool (asce7hazardtool.online), with a printout or screenshot attached to the plan set and referenced in general notes. Failure to include this data is a frequent plan review comment: “Provide documentation of the ultimate design wind speed for the project site, including a printout from the ASCE 7 Hazard Tool.”

General Notes and Explicit Code Citations

General notes must call out wind-borne debris protection and cite appropriate code sections: “All exterior glazing shall be protected in accordance with IRC Section R301.2.1.2 and ASCE 7-16.” Annotate both site plan and elevation sheets with wind speed region boundaries, using code-defined language directly: “This site is in a wind-borne debris region as defined by ASCE 7-16 §26.2; design wind speed: 145 mph ultimate per ASCE 7 Hazard Tool.”

Common plan review comment: “Detail the method of wind-borne debris protection for all exterior glazing, specifying compliance with ASTM E1996 and ASTM E1886.” All plans should include a general note confirming either impact-resistant glazing (“All window and door units shall be impact-rated per ASTM E1996/E1886 or have provision for approved impact-resistant coverings.”) or referencing more specific solutions detailed elsewhere in the set.

Drawing Delineation of Protection Scope and Methods

  • Every opening subject to debris risk must be tagged with a call-out: “PROVIDE IMPACT-RATED GLAZING,” “REMOVEABLE STORM PANELS,” or a unique designation corresponding to storm shutter schedules.
  • On the general notes or legend sheet, define all tags, abbreviations, and describe alternative protection methods (e.g., acceptable removable shutters, panel specs).
  • Narrate any local Houston amendments that alter the code’s base language or methods (e.g., permitted alternatives for one- or two-story structures).

Failure to mark each protected opening is regularly cited: “Not all openings shown protected. Revise drawings to delineate method of impact protection for each opening.”

Developing Comprehensive Fenestration and Impact Protection Schedules

Window and door schedules on Houston residential submittals must transcend basic size/type grids and become the backbone of code compliance for impact and wind design. The permit reviewer expects not just dimensions and counts, but documentable performance characteristics, explicit references to tested product lines, and clarity on which test standards are met for every glazed opening.

Required Schedule Columns and Notations

  • Tag/Mark: Each unique fenestration unit labeled (e.g., W01, D02) and keyed directly to plan/elevation call-outs.
  • Location: Identifies room or façade (“Living, North Elevation”).
  • Type: Operational type (“Fixed,” “Casement,” “Sliding,” “Overhead Door”).
  • Quantity
  • Rough Opening (RO) and Finished Opening Dimensions: (e.g., “4040 RO: 48" x 48"; FINISHED: 47" x 47””).
  • Design Pressure (DP) Rating: (e.g., DP50, DP60) matched to wind speed zone and wall configuration per ASCE 7.
  • Impact Protection: Explicitly “Impact-Rated (Large Missile),” “Impact-Rated (Small Missile),” “Non-Impact with Approved Shutter,” etc.
  • Glazing Type: (“Laminated IGU,” “Tempered”)
  • Manufacturer/Series/Model: (e.g., “PGT Winguard 670 Double Hung”)
  • U-Factor/SHGC: Per IECC/IRC requirements for thermal performance.

All fenestration tagged on floor plans and elevations must match the schedule-W01 on the plan must read identically on the A-sheet schedule, with location and rating matching.

Plan Review Redlines: Ambiguity and Missing Performance Data

Omissions or ambiguity in schedules drive resubmittals. Common findings include:

  • “Missing DP ratings for window schedule; must show minimum DP per site wind load.”
  • “Impact design not declared-schedule must note Large Missile or Small Missile rating AND certification standard per ASTM E1996/E1886.”
  • “Manufacturer series/model omitted; provide so TDI or Miami-Dade approval can be verified.”

Schedule must indicate if the unit itself provides impact protection, or if code-compliant external shutters/panels are relied upon for compliance-no field ambiguity is tolerated at plan review.

Keynoting and Drawing Cross-Referencing

  • Windows and doors annotated (“W02”) on plans/elevations must correspond exactly to schedule entries, with a legend or key sheet if necessary.
  • Supplemental protection (shutter, panel, or system) referenced in both plan call-outs and in the schedule, for example “W03: Non-impact window w/ SH3 removable panel (see shutter schedule).”
  • For any “field verify” entries, include with a bolded statement: “Final selections must not result in lower impact or DP rating than shown. Shop drawings/specifications to be submitted for record prior to fabrication.”

Inconsistent or incomplete cross-references are a top cause for “cloud and resubmit” directives.

Documenting Energy and Structural Ratings

  • Window and door SHGC and U-factor must comply with Houston's adopted energy conservation requirements (2021 IECC; SHGC ≤ 0.25, U-factor per current local path).
  • DP ratings must be calculated per site-specific wind pressures, not default. Attach calculation or TDI lookup result supporting DP selection with permit drawing submittal.

Failure mode: “Non-compliance with energy or wind DP-submit product data and justification for all units.”

Drafting Anchorage and Flashing Details for Impact-Rated Fenestration

Anchorage and flashing details must move from generic symbols to performance-focused, assembly-specific scaled details. Houston reviewers scrutinize both code/standard compliance and the presence of precise manufacturer-driven installation data. Per IRC R703.4 and R703.4.1, “approved corrosion-resistant flashing shall be installed at all exterior window and door openings... Installation shall be per the fenestration manufacturer's installation instructions.”

Head, Jamb, and Sill Details by Wall Type

Scaled section details must be provided for each unique wall/fenestration intersection:

  • Wood-Frame Walls: Flashing over header, shingle-lapped over WRB, continuous pan flashing with end dams at sill. Fasteners per MII (e.g., #10 stainless screws at 6” o.c. penetrating 1.5” into framing; for PGT Winguard, see their MII for specific anchor points).
  • Masonry Veneer: Lintel above window, through-wall flashing extending out of veneer, pan or subsill flashing extending beyond face brick with weep holes above, anchors into CMU or backup wall (e.g., minimum 2” embedment using Tapcon or sleeve anchors per catalog).
  • Stucco: Flashing and WRB integrated with stucco base coat; pan flashing under sill extends to finish face, jamb/head flashing lapped over WRB, all sealants per system requirements; anchor as for wood frame unless MII specifies otherwise.

Unacceptable: any generic note such as “anchor per manufacturer; provide flashing as required.” Plan reviewers demand non-generic detailing:
“Insufficient anchorage details-detail must show fastener type, size, spacing, embedment per manufacturer and wind load, not generic note.”

Material and Dimensional Specifications for Anchors and Flashing

Permit drawings should list:

  • Fastener: “#10 x 2 1/2” 300-series SS screws @ 6” o.c., 1.5” min. penetration into wood framing, as shown, per [MIII page].”
  • Flashing: “Self-adhered butyl-based membrane complying with AAMA 711, 9” vertical lapping over WRB at jamb; pan flashing of 24ga. aluminum, fully sealed to sill framing.”
  • Embedment: “Anchors into CMU backup min. 2” embedment.”

Explicitly dimension rough openings (e.g., “RO to be 1/2” wider/taller than unit; shim space to accommodate insulation and sealant per MII”).

Sheet Call-Outs, Detail Reference Conventions, and Referencing MIIs

  • Detail tags coordinated with wall section cuts; reference both wall type and specific window/door code (“2/A501 WOOD STUD WINDOW HEAD (TYP. IMPACT UNITS)”).
  • All flashing and anchor details cross-labeled with scheduled fenestration (“Detail applies to all W01, W03, and D01 units”).
  • Attach or reference MIIs-reviewers will redline: “Installation details/depths must be per MII. Attach MII page to permit set or provide detail that matches manufacturer’s.”

Drawing Integration of Permanent and Removable Storm Shutter Systems

Not all window and door assemblies shipped into Houston are inherently impact-rated. For these, IRC R301.2.1.2 allows use of approved storm shutters or panels, provided all details-from deployment positions to anchorage, storage, and obstruction of egress-are drawn explicitly on the permit sheets.

Graphical Representation of Shutter Systems

  • Plans and elevations must depict both deployed (solid) and stowed (dashed or noted) positions of all shutter systems-accordion, roll-down, panel, or fabric. For example: “SH2-Alum. Roll-Down Shutter, Deployment shown; stowed in integrated headbox.”
  • Schedule each shutter type (accordion, panel, fabric, roll-down) with product info, impact rating (“ASTM E1996/E1886 Large Missile”), and installation location.
  • Call-outs on plans must match schedule: “W05-relies on SH01 panel system; see Sheet A602, Shutter Schedule and Details.”

Depicting Attachment Hardware and Storage

  • Anchor details for all systems required (“Provide detailed attachment methods for storm shutters, including fastener type, size, spacing, and substrate compatibility.”).
  • Show section details for tracks, anchor clips, headboxes, or receiver angles, with dimensions. Example: 2” x 1/8” aluminum angle, fastened @ 12” o.c. with 1/4” Tapcon to masonry backup.
  • Label all permanently installed tracks/anchors on interior elevations; call out “anchors to remain when panels are not deployed.”
  • For removable panels/fabric, indicate clearly on floor plan the designated storage location-“Panel Storage: Garage North Wall, 3’-0” x 7’-0” clear area, outside egress clearances.”

Code-Compliant Details and Manufacturer Approval

Removable panels must be:

  • 7/16” min. structural wood panel (per IRC 301.2.1.2.1) with fastener schedule and permanent anchors installed in building; panels clearly labeled for each opening.
  • Non-combustible/Corrugated aluminum, or approved fabric, with product approval data attached to plan set.
  • All fasteners called out by type, size, and embedment; e.g., “1/4” x 3” Tapcon anchors with 1/8” stainless panel clips at 12” o.c. perimeter.”
  • All drawings/notes state: “Installation/operation of panels/shutters per manufacturer’s instructions and attached schedule. Egress must not be obstructed when stowed.”

Most common plan review redlines:

  • “Provide details of each shutter attachment and show stowed/deployed position.”
  • “Designated storage area for removable panels not indicated.”
  • “Ensure storm panels do not obstruct door or window egress when stowed.”

Addressing Houston Plan Review Comments and Resubmission Strategies for Fenestration Protection

The City of Houston’s Plan Review Division enforces a workflow where redline comments are both granular and strictly code-cited. Fenestration protection is the focus of many initial resubmittals for residential permits when plans lack depth in documentation or are ambiguous in code or standard reference. The process can either be expedited or repeatedly delayed depending on the drafter’s rigor in clouding revisions, composing precise responses, and addressing every deficiency head-on.

Common Plan Review Redlines: What to Expect

  • “Missing impact ratings”: All windows and doors must have clear performance references (ASTM E1996/E1886).
  • “Insufficient anchorage details”: Plans must depict fastener details aligned with MIIs and local code for all impact-rated and protected fenestration.
  • “Not all openings shown protected”: Omission of protection for just one window or door triggers mandatory revision.
  • “Protection method must be product- and code-specific, not generic.”

Strategies for Effective Responses and Timely Resubmission

Upon picking up a marked set, take these direct actions:

  • Cloud all changes: Overlay all drawing revisions in a distinctive cloud (not revision triangle), per Houston convention, so the reviewer locates every update quickly. This includes clouding every new note, detail, or schedule update responding to redlines.
  • Explicit revision notes: Beside each clouded change, add boxed, numbered notes: “1. Impact resistance rating added per IRC R301.2.1.2,” “2. Anchorage per PGT MII p.5” etc.
  • Detailed response letter: Submit a typed letter with the resubmittal, itemizing each City of Houston comment, the sheet/detail revised, summary of how addressed, and explicit reference to code (e.g., “R301.2.1.2, IRC 2021 Houston Amendments, ASCE 7-16, MII attached”).
  • Attach supporting documentation: For every product where impact or anchorage is in question, attach manufacturer spec, TDI approval, or Miami-Dade NOA printout. Highlight test references matching those scheduled and called out on the plans.

Detailing Unambiguous Call-Outs and Plan Conventions

Permit sets must become a self-contained, code-verified record and field document:

  • Every impact-resistant unit labeled “IMPACT” or “IMPACT-LARGE MISSILE/ASTM E1996/E1886,” with schedule and plan cross-reference.
  • Non-impact units annotated as “w/ SH3 Aluminum Panel Shutter, see details, Sheet A602.”
  • All anchorage (head, jamb, sill) details referenced with specific schedule/model number, MII/NOA reference, and code standard (“FL #13885.1, DP60, ASTM E1886 Large Missile”).
  • Clouded revisions and boxed notes visible at both whole-building plans and at detail scale.

Examples of Effective Responses to Redlines

  • Redline: “Missing impact rating for bedroom windows.”
    Response: Clouded revision on Sheet A601; window schedule updated to show “Impact (Large Missile, ASTM E1996/E1886, PGT Winguard Series).” Manufacturer NOA attached, W02 call-out added to affected elevation.
  • Redline: “Insufficient anchorage: detail anchorage for all impact windows.”
    Response: Scaled details 5/A701-7/A701 added with fastener type, size, spacing, embedment. Notes: “Anchorage as per PGT Winguard MII, attached. Fasteners: #10x2.5” SS, 6” o.c. into 1.5” min. framing.”
  • Redline: “Not all openings shown protected.”
    Response: All glazed openings tagged on floor plans and elevations, with legend clarifying protection method. “SH3 Aluminum Panels” storage/installation described; all entry points detailed for means of egress compliance.

Expediting Approval: Avoiding Repeat Redlines

The Plan Review Division will require a new resubmittal if any item remains ambiguous. Proactive thoroughness-clouding, notes, table cross-referencing, attached technical sheets-is the only path to first-pass approval. For fenestration, every sheet must tell a complete, self-explanatory story: region, protection type, dimensions, structural and impact performance, anchorage, and emergency egress compliance, each paired to a code citation or third-party approval.

Conclusion

For Houston residential projects subject to hurricane wind-borne debris risks, drawing sets must move from generic intent to project- and product-specific technical clarity. Every step-region mapping, schedule development, product selection, anchorage and flashing detailing, shutter integration, and resubmission process-requires explicit code citation and traceable product documentation, confirmed by clouded, annotated drawing revisions. Meticulous coordination of all drawings, notes, and supporting material provides a clear path to permit approval and job-site clarity, ensuring both code compliance and safety in high-wind events.
